| Brand Name : | Xinghe |
| Model Number : | zlp800 / zlp630 |
| Certification : | ISO CE |
| Price : | FOB Tianjin 1700~2300 USD/SET suspended platform |
| Payment Terms : | t/t l/c western union |
| Supply Ability : | 400sets/month suspended platform |
| Delivery Time : | 7~10 days after receiving the deposit |
5 years warranty zlp630/zlp800 suspended work platform / lifting gondola / hanging scaffolding for building maintenance
| ZLP SUSPENDED PLATFORM / GONDOLA / CRADLE / ANDAMIOS COLGANTES |
| PLATFORM DESCRIPTION |
(1) WorkingPlatform (2) Hoist Assembly (3) Satety Lock
(4) Electric Control Panel(5) Suspension Mechanism(6) Cable(7) Wire rope
2. Usage of Suspended platform
(1) Facade maintenance,paiting and cleaning of high building
(2) Window cleaning and installation
(3) Construction inspection and maintenance of big-size tanks,chimneys ,dams, bridges
(4) Maintenance , cleaning ,painting of big ship
| Technical Parameters |
| Item | ZLP250 | ZLP500 | ZLP630 | ZLP800 | ZLP1000 |
| Rated Loading | 250KG | 500KG | 630KG | 800KG | 1000KG |
| Speed | ~9.5 m/min | ~9.5 m/min | ~9.5 m/min | ~8.5m/min | ~8.3m/min |
| Size | L :1m ,2m,2.5,3m; W: 0.69m; H: 1.18m | ||||
| Suspension Mechanism | Rated exerted length of front beam | 1.1m~1.5m | |||
| Terrain clearance of front beam | 1.45m~1.75m | ||||
| Hoist | |||||
| Item | LTD63 | LTD80 a drive | LTD80 s drive | ||
| Voltage | 220v/ 415v/380v 50/60 hz 3 phase / single phase | ||||
| Power | 2*1.5kw | 2*1.8/2.0kw | 2*2.2kw | ||
| Speed | 1400 n/min | ||||
| Safety lock | ||
| Item | Anti-proofing LS30 | |
| Angle of tilted locking rope | 3°~8° | |
| Allowable impact force | 30KN | |
| Wire rope | ||
| Type | 4*31SW+FC-φ8.3 | 4*31SW+FC-φ8.6 |
| Control panel | ||
| Brand | CHNT | Schneider |
| Conter weight | ||
| Iron cast | Cement | Hot galvnized steel with concrete |
| PLATFORM DRAWING |
 | PLATFORM DRAWING |
| Suspension Mechanism Drawing |  |
1.Suspension mechanism &Platform
| Surface treatment with hot galvanized craft, the steel is not easy to rust . |
| The service life can be as long as 15 years , more durable than spraying process. |
2.Hoist
| With famous brand of motor , large braking torque |
| Inside gear is 100% copper, the warranty is 5 years. |
| unique anti-rope clamping device , when rope is clamped ,alarming rings, hoist will stop working , safety is increased, maintenance cost is reduced |
| Lubrication oil is 220#industry gear oil.Lubrication oil is 220#industry gear oil. |
3.Safety lock
| The lock cylinder uses special stainless steel , with strong impact resistance, higher |
| toughness,wear resistant, long services life ,safe and reliable |
4.Electric control system
| The electric components uses famouse brand CHNT, SCHNEIDER,quality is guaranteed |
| Perfect circuit design, including leakage protection, current overload protection,emergency braking,operate simply. |
5.Wire rope
| Our supplier is Jiangsu Fasten Steel Cord Co.,Lt---Chinese famous brand"FASTEN" |
6.Cable
| Using national standard cable 2.5*3+1.5*2, using life is longer |
| SPECIAL DESIGN |
Hoist and safety lock are packed in one plywood case, size 610*310*340mm;
Control box/ control panel is packed in a plywood case,size 570*440*270mm;
Products will be package by plywood case for LCL
For the whole container , the goods will be packaged by pallet.
One 20' container can put about 8-10 sets suspended platform
Langfang Xinghe Industry Co,Ltd, established in 1980 year,we are a professional factory.
Main products :
1. zlp250 / zlp500 / zlp630 /zlp800 /zlp1000
2. Ltd hoist : LTD63,LTD80 a drive , LTD80 s drive
3. Safety lock : ant-proofing safety lock & centrifuge safety lock
4. Control panel: CHNT & Schneider
5. All components
We can customize for you and welcome OEM
With CE & ISO, The quantity of exported countries are more than 20, India , Malaysia , Indonesia, Philippines, Spain, Portugal, Honduras, Chile, Peru, Colombia, UAE, SA, Bahrain ect.
Our goal is to provide safest & most convenient machinery all around world and supply the best after-sales service
